Dell ECS EX Series

Table 33. EX500 PDU three-phase Delta and WYE zone A/B mapping (continued)
PDU outlet Branch Component Line cord per zone
23 8 Empty 1
22 8 Empty 1
21 7 Node 16 1
20 7 Node 15 1
19 7 Node 14 1
18 6 Node 13 1
17 6 Node 12 1
16 6 Node 11 1
15 5 Node 10 1
14 5 Node 9 1
13 5 Node 8 1
12 4 FE Switch2 1
11 4 FE Swtich 1 1
10 4 Tray/Light Bar 1
9 3 BE Switch 2 1
8 3 BE Switch 1 1
7 3 Node 7 1
6 2 Node 6 1
5 2 Node 5 1
4 2 Node 4 1
3 1 Node 3 1
2 1 Node 2 1
1 1 Node 1 1
Table 34. EX500 2U PDU single-phase zone A/B mapping
PDU outlet Branch Component Line cord per zone
24 6 Empty 3
23 6 Empty 3
22 6 Empty 3
21 6 Node 16 3
20 5 Node 11 2
19 5 Node 10 2
18 5 Node 9 2
17 5 Node 8 2
16 4 Node 4 1
15 4 Node 3 1
14 4 FE Switch2 1
13 4 FE Swtich 1 1
EX500 Platform 75
