The EX300 appliance connections to 0U PDU and 2U PDU outlets are listed in the following tables.

Table 42. EX300 0U PDU cabling

PDU cabling PS1 outlet numbers PS2 outlet numbers Line cord per zone (Single phase)

Zone B Zone A

Black cables Gray cables

Node 16 21 21 2

Node 15 20 20 2

Node 14 19 19 2

Node 13 18 18 1

Node 12 17 17 1

Node 11 16 16 1

Node 10 15 15 1

Node 9 14 14 1

Node 8 13 13 1

FE 2 12 12 1

FE 1 11 11 1

Service Tray and Light Bar 10 10 1

BE 2 9 9 1

BE 1 8 8 1

Node 7 7 7 1

Node 6 6 6 1

Node 5 5 5 1

Node 4 4 4 1

Node 3 3 3 1

Node 2 2 2 1

Node 1 1 1 1

Table 43. EX300 2U PDU cabling

2U PDU cabling PS1 outlet numbers PS2 outlet numbers Line cord per zone (Single phase)

Zone B Zone A

Black cables Gray cables

Node 16 21 21 3

Node 15 12 12 3

Node 14 11 11 3

Node 13 10 10 3

Node 12 9 9 3

Node 11 20 20 2

Node 10 19 19 2

Node 9 18 18 2

Node 8 17 17 2

102 EX300 Platform

Dell ECS EX Series User Manual
