Table 32. EX500 0U PDU single-phase zone A/B mapping (continued)
PDU outlet Branch Component Line cord per zone
21 7 Node 9 2
20 7 Node 8 2
19 7 Node 7 2
18 6 Empty 1
17 6 Empty 1
16 6 Empty 1
15 5 Empty 1
14 5 Empty 1
13 5 Empty 1
12 4 FE Switch 2 1
11 4 FE Switch 1 1
10 4 Tray/Light Bar 1
9 3 BE Switch 2 1
8 3 BE Switch 1 1
7 3 Empty 1
6 2 Node 6 1
5 2 Node 5 1
4 2 Node 4 1
3 1 Node 3 1
2 1 Node 2 1
1 1 Node 1 1
Table 33. EX500 PDU three-phase Delta and WYE zone A/B mapping
PDU outlet Branch Component Line cord per zone
37 12 Empty 1
36 12 Empty 1
35 12 Empty 1
34 12 Empty 1
33 11 Empty 1
32 11 Empty 1
31 11 Empty 1
30 10 Empty 1
29 10 Empty 1
28 10 Empty 1
27 9 Empty 1
26 9 Empty 1
25 9 Empty 1
24 8 Empty 1
74 EX500 Platform
