Dell ECS EX Series

Table 18. EXF900 Single-Phase 2U PDU Cabling with Aggregation Switch
PDU Outlet Component Line cord per zone
PDU2 16 Node 13 4
PDU2 15 Node 12 4
PDU2 14 Empty 4
PDU2 13 Empty 4
PDU2 4 Node 15 4
PDU2 3 Node 14 4
PDU2 2 Empty 4
PDU2 1 Empty 4
PDU1 24 Node 11 3
PDU1 23 Node 10 3
PDU1 22 Empty 3
PDU1 21 Empty 3
PDU1 20 Empty 2
PDU1 19 Node 7 2
PDU1 18 AGG SW2 2
PDU1 17 AGG SW1 2
PDU1 16 Node 4 1
PDU1 15 Node 3 1
PDU1 14 Empty 1
PDU1 13 Zone B Service Tray/Zone A Light Bar 1
PDU1 12 Node 9 3
PDU1 11 Node 8 3
PDU1 10 Empty 3
PDU1 9 Empty 3
PDU1 8 Node 6 2
PDU1 7 Node 5 2
PDU1 6 FE SW2 2
PDU1 5 FE SW1 2
PDU1 4 Node 2 1
PDU1 3 Node 1 1
PDU1 2 BE SW2 1
PDU1 1 BE SW1 1
EXF900 Platform 45
