Figure 98. Installing the serial COM port
Next steps
1. Install the expansion card riser.
2. Follow the procedure listed in After working inside your system.
System board
Removing the system board
Prerequisites
CAUTION:
If you are using the Trusted Platform Module (TPM) with an encryption key, you may be prompted
to create a recovery key during program or System Setup. Be sure to create and safely store this recovery key.
If you replace this system board, you must supply the recovery key when you restart your system or program
before you can access the encrypted data on your drives.
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the following components:
a. Air shroud
b. Cooling fan modules
c. Procesor and heat sink module
d. Memory modules
e. Expansion card risers
108
Installing and removing system components
