Dell EMC XC Core XC650 User Manual

Figure 83. Removing the OCP card
Next steps
1. Replace the OCP card.
Installing the OCP card
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in the Before working inside your system.
3. Remove the expansion card riser.
CAUTION:
Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
Steps
1. Open the blue latch on the system board.
2. Slide the OCP card into the slot in the system.
3. Push until the OCP card is connected to the connector on the system board.
4. Close the latch to lock the OCP card to the system.
Installing and removing system components
93

Dell EMC XC Core XC650 Specifications

General

Brand	Dell
Model	EMC XC Core XC650
Category	Server
Language	English
