Dell EMC XC Core XC650 User Manual

Table 14. 10 x 2.5-inch NVMe and 2 x 2.5-inch NVMe
From To
SL1_CPU2_PB1 (Signal connector on system board) DST_PA1 (backplane signal connector)
SL2_CPU2_PA1 (Signal connector on system board) DST_PB1 (backplane signal connector)
SL3_CPU1_PB2 (Signal connector on system board) DST_PA2 (backplane signal connector)
SL4_CPU1_PA2 (Signal connector on system board) DST_PB2 (backplane signal connector)
PADDLE R1d (Paddle R1d connector on system board) DST_PA3 (backplane signal connector)
SIG_PWR_1 (system board power connector) BP_PWR (backplane power connector)
SIG_PWR_0 (system board power connector) REAR_HDD_PWR (Rear HDD module power connector)
PADDLE R1d (Paddle R1d connector on system board) DST_SA1 (rear backplane signal connector)
System memory
System memory guidelines
The XC Core XC650 system supports DDR4 registered DIMMs (RDIMMs), Load Reduced DIMM (LRDIMMs) and Intel Persistent
Memory 200 series (BPS). System memory holds the instructions that are started by the processor.
Your system memory is organized into eight channels per processor (two memory sockets per channel),16 memory sockets per
processor and 32 memory sockets per system.
Installing and removing system components
51
