Figure 40. Memory channels
Memory channels are organized as follows:
Table 15. Memory channels
Processor Channel
A
Channel
B
Channel C Channel D Channel E Channel F Channel G Channel H
Processor 1 Slots A1
and A9
Slots A5
and A13
Slots A3
and A15
Slots A7
and A15
Slots A2 and
A10
Slots A6
and A14
Slots A4 and
A12
Slots A8 and
A16
