Dell EMC XC Core XC650 User Manual

Table 23. Intel Persistent Memory 200 series (BPS) Configuration 5 - 8 x RDIMMs/ LRDIMMs, 8 x Intel
Persistent Memory 200 series (BPS) per processor (continued)
Total No of
RDIMMs /
LRDIMMs
Total No of
Intel
Persistent
Memory 200
series (BPS)
DIMMs
1 R/LRDIMM
capacity (GB)
1 Intel
Persistent
Memory 200
series (BPS)
capacity (GB)
Total Standard
Memory Capacity
(GB)
Total PM
Capacity
(GB)
Supported Modes
8 8 64 256 512 2048 MM or AD
8 8 128 256 1024 2048 AD
8 8 256 256 2048 2048 AD
8 8 16 512 128 4096 AD
8 8 32 512 256 4096 MM or AD
8 8 64 512 512 4096 MM or AD
8 8 128 512 1024 4096 MM or AD
Table 24. Intel Persistent Memory 200 series (BPS) Configuration 6 - 12 x RDIMMs/ LRDIMMs, 2 x Intel
Persistent Memory 200 series (BPS) per processor
Total No of
RDIMMs /
LRDIMMs
Total No of
Intel
Persistent
Memory 200
series (BPS)
DIMMs
1 R/LRDIMM
capacity (GB)
1 Intel
Persistent
Memory 200
series (BPS)
capacity (GB)
Total Standard
Memory Capacity
(GB)
Total PM
Capacity
(GB)
Supported Modes
12 2 16 128 192 256 AD
12 2 32 128 384 256 AD
12 2 64 128 768 256 AD
12 2 128 128 1536 256 AD
12 2 16 256 192 512 AD
12 2 32 256 384 512 AD
12 2 64 256 768 512 AD
12 2 128 256 1536 512 AD
12 2 16 512 192 1024 AD
12 2 32 512 384 1024 AD
12 2 64 512 768 1024 AD
12 2 128 512 1536 1024 AD
Removing a memory module
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the air shroud.
WARNING:
The memory modules are hot to touch for some time after the system has been powered off. Allow
the memory modules to cool before handling them.
NOTE: To ensure proper system cooling, memory module blanks must be installed in any memory socket that is not
occupied. Remove memory module blanks only if you intend to install memory modules in those sockets.
58 Installing and removing system components
