CAUTION: Press and eject any installed card from the media-card reader.
Identifier GUID-DEA55279-6FE6-4A1F-A152-21F8A5572B33
Status Released
Recommended tools
The procedures in this document may require the following tools:
• Phillips screwdriver
• Plastic scribe
Identifier GUID-7A78925A-E09E-447B-800A-3DC937EF2DD5
Status Released
Screw list
Table 1. Screw list
Component Secured to Screw
type
Quantity Screw image
Stand Middle frame M4x6 6
Hard-drive
bracket
Middle frame M3x5 1
Hard drive Hard-drive
bracket
M3x3.5 3
System-board
shield
System board M3x5 6
Fan Middle frame M3x5 3
Solid-state drive System board M2x3.5 1
13
