Dell inspiron 27 7000 - Procedure

141 pages

To Next Page

To Previous Page

Identifier GUID-5931EF4F-2EAA-463D-886C-090DE463D52B

Status Released

Procedure

1 Remove the six screws (Step type M3x5.6) that secure the front bezel to the

display panel.

2 Turn the display panel over.
