Procedure
1 Locate the wireless card on the system board.
2 Remove the screw (M2x3.5) that secures the wireless-card bracket and the
wireless card to the system board.
3 Slide and lift the wireless-card bracket o the wireless card.
4 Disconnect the antenna cables from the wireless card.
83
