Dell inspiron 27 7000 - Procedure

141 pages

To Next Page

To Previous Page

Identifier GUID-4D91EF9F-1C7D-44E4-B636-96D7AAA7DFE3

Status Released

Procedure

1 Locate the memory modules on the system board.

2 Using your ngertips, gently spread apart the securing clips at each end of the

memory-module slot until the memory module pops up.
