Dell Latitude 5280 - Installing Optional M.2 SSD; Hard Drive; Removing Hard Drive Assembly

Installing optional M.2 SSD
1 Insert the SSD clip into the slot on the computer.
2 Tighten the M2*3 screw to secure the SSD clip to the computer.
3 Insert the SSD into the connector on the computer.
4 Place the SSD bracket over the SSD and tighten the M2*3 screw to secure it to the computer.
5 Install the:
a battery
b base cover
6 Follow the procedure in After working inside your computer.
Hard drive
Removing hard drive assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
3 To remove the hard drive assembly:
a Disconnect the hard drive cable from the connector on the system board.
b Remove the screws that secure the hard drive assembly to the computer.
