Dell Latitude 5280 User Manual

The Enhanced Pre-boot System Assessment window displays, listing all devices detected in the computer. The diagnostics starts
running the tests on all the detected devices.
3 On the boot menu screen, select the Diagnostics option.
The Enhanced Pre-boot System Assessment window displays, listing all devices detected in the computer. The diagnostics starts
running the tests on all the detected devices.
4 If you wish to run a diagnostic test on a specific device, press Esc and click Yes to stop the diagnostic test.
5 Select the device from the left pane and click Run Tests
6 If there are any issues, error codes are displayed.
Note the error code and contact Dell.
Device status lights
Table 5. Device status lights
Icon Name Description
Power
status light
Turns on when you turn on the computer and blinks when the computer is in a power management mode.
Hard drive
status light
Turns on when the computer reads or writes data.
Battery
charge
indicator
Turns on steadily or blinks to indicate battery charge status.
The device status LEDs are usually located either on the top or left side of the keyboard. They display the storage, battery and wireless
devices connectivity and activity. Apart from that they can be useful as a diagnostic tool when there's a possible failure to the system.
NOTE
: The position of the power status light may vary depending on the system.
The following table lists how to read the LED codes when possible errors occur.
Table 6. Battery charge LED indicator
Amber blinking pattern Problem description Suggested resolution
2,1 CPU CPU failure
2,2 System board: BIOS ROM System board, covers BIOS corruption or ROM error
2,3 Memory No memory/RAM detected
2,4 Memory Memory/RAM failure
2,5 Memory Invalid memory installed
2,6 System board: Chipset System board/Chipset error
2,7 LCD Replace the system board
3,1 RTC Power Failure CMOS battery failure
3,2 PCI/Video PCI or video card/chip failure
3,3 BIOS Recovery 1 Recovery image not found
3,4 BIOS Recovery 2 Recovery image found but invalid
The blinking patterns will consist of 2 set of numbers being represented by (First Group: Amber blinks, Second Group: White blinks)
84
Diagnostics

Dell Latitude 5280 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Business
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
3D	No
AC adapter included	Yes
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA III
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Pixel pitch	0.2025 x 0.2025 mm
Display surface	Matt
Display diagonal	12.5 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Audio chip	Realtek ALC3253
Speaker power	2 W
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	0.92 MP
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
SmartCard slot	-
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system architecture	64-bit
Battery voltage	11.4 V
Battery capacity	42 Wh
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.34 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	3 MB
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-7300 Mobile Series
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.7 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR340
Processor ARK ID	97472
Processor package size	42 X 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	211.3 mm
Width	305.15 mm
Height	21.4 mm
Weight	1360 g
