Dell Latitude 5280 - Installing Touchpad Panel; Smartcard Module; Removing Smart Card Reader Board

Installing touchpad panel
1 Align the touchpad panel with the tabs on the computer.
2 Tighten the screws to secure the touchpad panel to the computer.
3 Connect the touchpad panel cable to the connector.
4 Affix the adhesive tapes to secure the speaker cable to the touchpad panel.
5 Affix the smart card reader board cable.
6 Connect the smart card reader board to the connector.
7 Install the:
a chassis frame
b SSD card
c WLAN card
d battery
e base cover
8 Follow the procedure in After working inside your computer.
SmartCard module
Removing smart card reader board
1 Follow the procedure in Before working inside your computer.
2 Remove the:
32
Removing and installing components
