Dell Latitude 5280 - Installing Keyboard Trim; Removing Keyboard

Installing keyboard trim
1 Place the keyboard trim on the keyboard and press on the edges until it clicks in place.
2 Follow the procedure in After working inside your computer.
Removing keyboard
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
c keyboard trim
3 Lift the latch and disconnect the keyboard cable from the connector.
4 Turn over the computer and open the display.
5 To remove the keyboard:
a Remove the M2*2 screws that secure the keyboard to the computer [1].
b Pry the keyboard from the edge and lift it away from the computer [2].
WARNING
: Make sure you pull the keyboard cable routed under the computer to avoid any damage to the
keyboard cable.
22 Removing and installing components
