Installing speaker
1 Insert the speaker module aligning it with the nodes on the chassis.
2 Route the speaker cable through the routing channels.
3 Affix the adhesive tapes to secure the speaker cable.
4 Install the:
a chassis frame
b heat sink assembly
c SSD card
d WLAN card
e battery
f base cover
5 Follow the procedure in After working inside your computer.
Display assembly
Removing display assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
c WLAN card
3 To disconnect the display cable:
Removing and installing components
37
