Dell Latitude 5280 User Manual

Navigation keys
NOTE: For most of the System Setup options, changes that you make are recorded but do not take effect until you restart the
system.
Keys Navigation
Up arrow Moves to the previous field.
Down arrow Moves to the next field.
Enter Selects a value in the selected field (if applicable) or follow the link in the field.
Spacebar Expands or collapses a drop‐down list, if applicable.
Tab Moves to the next focus area.
NOTE: For the standard graphics browser only.
Esc Moves to the previous page until you view the main screen. Pressing Esc in the main screen displays a message
that prompts you to save any unsaved changes and restarts the system.
F1 Displays the System Setup help file.
System Setup overview
System Setup allows you to:
• Change the system configuration information after you add, change, or remove any hardware in your computer.
• Set or change a user-selectable option such as the user password.
• Read the current amount of memory or set the type of hard drive installed.
Before you use System Setup, it is recommended that you write down the System Setup screen information for future reference.
CAUTION
: Unless you are an expert computer user, do not change the settings for this program. Certain changes can cause
your computer to work incorrectly.
Accessing System Setup
1 Turn on (or restart) your computer.
2 After the white Dell logo appears, press F2 immediately.
The System Setup page is displayed.
NOTE
: If you wait too long and the operating system logo appears, wait until you see the desktop. Then, shut down or
restart your computer and try again.
NOTE: After the Dell logo appears, you can also press F12 and then select BIOS setup.
General screen options
This section lists the primary hardware features of your computer.
Option
Description
System Information This section lists the primary hardware features of your computer.
• System Information: Displays BIOS Version, Service Tag, Asset Tag, Ownership Tag, Ownership Date,
Manufacture Date, and the Express Service Code.
System setup options 63

Dell Latitude 5280 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Business
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
3D	No
AC adapter included	Yes
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA III
Storage media	HDD
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
Pixel pitch	0.2025 x 0.2025 mm
Display surface	Matt
Display diagonal	12.5 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Audio chip	Realtek ALC3253
Speaker power	2 W
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	0.92 MP
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
SmartCard slot	-
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system architecture	64-bit
Battery voltage	11.4 V
Battery capacity	42 Wh
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.34 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	3 MB
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-7300 Mobile Series
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.7 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR340
Processor ARK ID	97472
Processor package size	42 X 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	211.3 mm
Width	305.15 mm
Height	21.4 mm
Weight	1360 g
