Installing keyboard
1 Hold the keyboard and route the keyboard cable through the placeholder.
2 Place the keyboard to align with the screw holders on the computer.
3 Tighten the M2*2 screws to secure the keyboard to the computer.
4 Connect the keyboard cable to the connector.
5 Install the:
a keyboard trim
b battery
c base cover
6 Follow the procedure in After working inside your computer.
Heat sink
Removing heatsink assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
Removing and installing components
23
