Page #10 background imageLoading...
Page #10 background image
NOTE: The color of your computer and certain components may appear differently
than shown in this document.
To avoid damaging your computer, perform the following steps before you begin
working inside the computer.
1. Ensure that your work surface is flat and clean to prevent the computer
cover from being scratched.
2. Turn off your computer (see
Turning Off Your Computer
).
3. If the computer is connected to a docking device (docked) such as the
optional Media Base or Battery Slice, undock it.
CAUTION: To disconnect a network cable, first unplug the cable from your
computer and then unplug the cable from the network device.
4. Disconnect all network cables from the computer.
5. Disconnect your computer and all attached devices from their electrical
outlets.
6. Close the display and turn the computer upside-down on a flat work
surface.
NOTE: To avoid damaging the system board, you must remove the main battery
before you service the computer.
7. Remove the main battery (see
Battery
).
8. Turn the computer top-side up.
9. Open the display.
10. Press the power button to ground the system board.
CAUTION: To guard against electrical shock, always unplug your computer from the
electrical outlet before opening the display.
CAUTION: Before touching anything inside your computer, ground yourself by
touching an unpainted metal surface, such as the metal at the back of the
computer. While you work, periodically touch an unpainted metal surface to
dissipate static electricity, which could harm internal components.
11. Remove any installed ExpressCards or Smart Cards from the appropriate
slots.
Recommended Tools
The procedures in this document may require the following tools:
Small flat-blade screwdriver
10

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell Latitude E6520 and is the answer not in the manual?

Dell Latitude E6520 Specifications

General IconGeneral
Bus typeDMI
SteppingJ1
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli3-2310M
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-2300 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.1 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)21
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM67 Express
HDD speed7200 RPM
HDD interfaceSATA
Optical drive typeDVD-RW
Card reader integratedYes
Total storage capacity320 GB
Display diagonal15.6 \
Display resolution1600 x 900 pixels
Native aspect ratio16:9
TypePC
Power supply typeAC/DC
Wireless technologyWireless LAN
Compliance industry standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots2x SO-DIMM
Internal memory2 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)1 x 2 GB
On-board graphics card ID0x116
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 3000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Audio systemHD
Front camera resolution (numeric)1.3 MP
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Networking topologyGigabit Ethernet
Operating system installedWindows 7 Professional
Operating system architecture32-bit
SmartCard slot-
Charging port typeDC-in jack
USB 2.0 ports quantity3
CardBus PCMCIA slots quantity0
Battery capacity60 Wh
Number of battery cells6
Keyboard layoutAZERTY
Pointing deviceTouchpad
Sustainability certificatesEPEAT Gold, ENERGY STAR
Processor codeSR04S
Processor ARK ID52220
Processor package size37.5 x 37.5 xrPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth258 mm
Width384 mm
Weight2500 g
Height (rear)34.2 mm
Height (front)28.3 mm
