Dell Latitude E6520 - Keyboard; Removing The Keyboard

Keyboard 21
Removing The Keyboard
1. Follow the procedures in Before Working On Your Computer .
2. Remove the keyboard trim .
3. Remove the battery .
4. Remove the base cover .
5. Remove the screws that secure the keyboard to the palm rest assembly
6. Flip the keyboard over.
7. Lift the clip to release the keyboard cable and disconnect it from the
computer
