Installing the back cover
1 Place the back cover on the system.
2 Press and hold the tab [1], and align the notches on the back cover with the slots on the middle frame.
3 Slide the back cover in the direction shown to lock the back cover tab under the latch on the system-board shield [2].
24
Removing and Installing components
