3 Install the following components:
a Base cover
b System board shield
c Back cover
d Stand
4 Follow the procedure in After working inside your computer.
System board
Removing the system board
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
c Hard drive
d Memory
e System board shield
f Intel Optane
g SSD
h WLAN card
i System fan
Removing and Installing components
71
