Dell OptiPlex 5260 - WLAN Card; Removing the WLAN Card

4 Install the following components:
a System board shield
b Back cover
c Stand
5 Follow the procedure in After working inside your computer.
WLAN card
Removing the WLAN card
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
c System board shield
3 To remove the WLAN card shield:
a Remove the two screws (M2x2.5) that secure the WLAN card shield to the system board [1].
b Remove the WLAN card shield from the system board [2].
