4 Install the following components:
a Back cover
b Stand
5 Follow the procedure in After working inside your computer.
Intel Optane
Removing the Intel Optane card
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
c System board shield
3 Remove the screw (M2x2.5) that secures the Intel Optane card to the system board [1].
4 Slide and remove the Intel Optane card from the card slot on the system board [2].
5 Remove the thermal pad [3].
Removing and Installing components
31
