Dell OptiPlex 5260 - System Fan; Removing the System Fan

3 Install the following components:
a system board shield
b Back cover
c Stand
4 Follow the procedure in After working inside your computer.
System fan
Removing the system fan
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
c System board shield
3 Disconnect the system fan cable from the socket on the system board [1].
4 Remove the three screws (M3x5) that secure the system fan to the display assembly base [2].
5 Lift the system fan away from the system [3].
Removing and Installing components
41
