Dell OptiPlex 5260 - Power Button Board; Removing the Power Button Board

2 Install the following components:
a I/O bracket
b Base cover
c System board shield
d Back cover
e Stand
3 Follow the procedure in After working inside your computer.
Power button board
Removing the power button board
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
c System board shield
d Base cover
e PSU
f PSU fan
3 To remove the power button board:
a Open the latch, and disconnect the power button board cable from the system board [1].
b Slide the power button board cable out from under the antenna cables [2].
c Peel o the power button board cable from the display assembly base [3].
d Slide the power button board cable out from under the antenna cables [4].
Removing and Installing components
79
