Dell OptiPlex 5260 - Page 70

2 To install the PSU cable:
a Route back the power supply cables through the retention clips in the chassis [1].
b Slide and replace the power supply socket on the chassis [2].
c Replace the single (M3x5) screw securing the power supply socket to the I/O bracket [3].
70
Removing and Installing components
