Dell OptiPlex 5260 - Page 68

5 To remove the Input and Output (I/O) bracket:
a Remove the three (M3x5) screws that secure the I/O bracket to the display assembly base [1].
b Lift the I/O bracket o the display assembly base [2].
68
Removing and Installing components
