Dell OptiPlex 5260 - Page 82

c Slide the power button board cable under the antenna cable [1].
d Slide the power button board cable under the antenna cable, then adhere the power button board cable to the display assembly
base [2].
e Slide the power button board cable into the socket on the system board and close the latch to secure the cable [3].
82
Removing and Installing components
