Dell PowerConnect 55xx Systems User Guide 451
The following is an example of the CLI commands:
show {current|pending} Displays the current or pending MST region
configuration.
show spanning tree mst-
configuration
Displays the MSTP configuration.
console(config)# spanning-tree mst configuration
console(config-mst)# instance 1 add vlan 10-20
console(config-mst)# name region1
console(config-mst)# revision 1
console(config)# interface gi1/0/1
console(config-if)# spanning-tree mst 1 port-priority 144
console(config)# spanning-tree mst max-hops 10
console(config)# spanning-tree mst configuration
console(config-mst)# instance 2 add vlan 21-30
console(config-mst)# name region1
console(config-mst)# revision 1
console(config-mst)# show pending
Pending MST configuration
Name: Region1
Revision: 1
Instance VLANs Mapped
-------- ------------
0 1-9,31-4094
1 10-20
2 21-30
Table 13-4. MSTP Properties CLI Commands (Continued)
CLI Command Description
