694 Dell PowerConnect 55xx Systems User Guide
2
To add a new counter, click
Add
, and enter the fields:
– Counter Set—Select the counter set. The possible options are:
•
Set 1
— Displays the statistics that contains all interfaces and
queues with a high DP (Drop Precedence).
•
Set 2
— Displays the statistics that contains all interfaces and
queues with a low DP.
– Interface — Select the unit/interface for which Queue statistics are
displayed.
– Queue — Select the queue on which packets were forwarded or tail
dropped.
Defining QoS Statistics Using CLI Commands
The following table summarizes the CLI commands for setting the fields in
the QoS Statistics pages.
The following is an example of the CLI commands:
Table 22-21. QoS Statistics CLI Commands
CLI Command Description
qos statistics queues set-number
{queue|all} {dp|all}
{[gigabitethernet|tengigabitethe
rnet]port-number|all}
no qos statistics queues set-
number
Enables QoS statistics for output
queues.
Use the no form of this command to
disable QoS statistics for output
queues.
clear qos statistics Clears the statistics
show qos statistics Displays the statistics
console(config)# qos statistics queues 1 all all all
