Table 1. Screw list (continued)
Component Screw type Quantity Screw image
M.2 solid state drive M2x2.5 2
M.2 solid state drive2 M2x2.5 2
Heat-sink for discrete graphics Captive screws
M2x5
8
3
GPU card M2x6
M2x5
4
3
Power-button board M2x3
M2x2
1
2
Power-button M2x3
M2x2
2
Speakers
NOTE: Only for 93 Whr
battery
M2x2 1
Inner frame M2x6
M2x2
M2x2.5
5
8
1
SD card reader M2x2 1
System board M2x6
M2x5
4
11
Display assembly M2.5x5
M2x5
6
4
