Table 4. System board replacement components (continued)
Sl. No Item
4 Hexagonal standoff nuts x4 (for models shipped with a
CAMM module)
NOTE:
● The hexagonal standoff nuts can be removed with a flat-head screwdriver.
● There are no absorbers or standoff nuts to be transferred for models that are shipped with a DIMM memory module
and without WWAN antennas.
Installing the system board
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the system board and provides a visual representation of the installation procedure.
72 Removing and installing components
