Dell Precision 7780 - Memory Modules; Removing the Memory Module; Installing the Memory Module

2. Follow the procedure in after working inside your computer.
Memory modules
Removing the memory module
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
About this task
NOTE: For models shipped with a SODIMM configuration.
The figure indicates the location of the memory module and provides a visual representation of the removal procedure.
Steps
1. Pry the securing clips from both side of the memory module until the memory module pops up.
2. Remove the memory module from the memory-module slot.
NOTE: Repeat the above steps if there are other .
Installing the memory module
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
Removing and installing components
31
