7. Replace the three (M2x5) screws to secure the display cable bracket in place.
8. Align the screw holes, and replace the four (M2x6) screws to secure the two PCB beam connectors to the system board
and the GPU card.
NOTE: For models shipped with an integrated GPU card, the PCB beam connectors are on the bottom and top-right
side of the GPU card. For models shipped with a discrete GPU card, the PCB beam connectors are at the bottom side of
the GPU card.
9. Connect the GPU power cable to the connector on the system board on the top side of the computer.
10. Lock the GPU power cable connector on the system board.
11. Connect the antennas to their connectors.
12. Replace the (M2x5) screw to secure the WLAN bracket to the system board.
Next steps
1. Install the inner frame.
2. Install the heat-sink for discrete graphics.
3. Install the secondary solid-state drive.
4. Install the primary solid-state drive.
5. Install the WWAN card.
6. Install the WLAN card.
7. Install the interposer board module.
8. Install the CAMM module or memory module.
9. Install the battery.
10. Install the SIM card.
11. Install the base cover.
12. Follow the procedure in after working inside your computer.
Coin-cell battery
Removing the coin-cell battery
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
3. Remove the SIM card.
4. Remove the battery.
5. Remove the CAMM module or memory module.
6. Remove the interposer board module.
7. Remove the WWAN card.
8. Remove the primary solid-state drive.
9. Remove the secondary solid-state drive.
10. Remove the heat-sink for discrete graphics.
11. Remove the inner frame.
12. Remove the system board.
About this task
The figure indicates the location of the coin-cell battery and provides a visual representation of the removal procedure.
74
Removing and installing components
