Steps
1. Place the SIM card into the SIM card slot.
2. Snap the SIM card cover down.
3. Slide the SIM card cover towards the right of the computer to lock the cover.
Next steps
1. Install the base cover.
2. Follow the procedure in after working inside your computer.
Compression Attached Memory (CAMM) module
Removing the Compression Attached Memory (CAMM) module
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
About this task
NOTE: For models shipped with a CAMM module
The figure indicates the location of the CAMM module and provides a visual representation of the removal procedure.
28
Removing and installing components
