3. Place the WWAN card bracket above the WWAN card to secure the antenna cables.
4. Replace the (M2x2) screw to secure the WWAN card bracket to the system board.
NOTE: For instructions on how to find your computer's IMEI (International Mobile Station Equipment Identity) number,
see the knowledge base article 000143678 at https://www.dell.com/support/.
Next steps
1. Install the base cover.
2. Follow the procedure in after working inside your computer.
Solid State Drive
Removing the primary M.2 Solid-state drive
Prerequisites
NOTE: For computers shipped with M.2 2280 or 2230 Solid-state drive that is installed in slot 5.
1. Follow the procedure in before working inside your computer.
2. Remove the base cover.
NOTE: Follow this procedure only if the computer is shipped without SSD door configuration).
About this task
The figure indicates the location of the primary M.2 SSD and provides a visual representation of the removal procedure.
40
Removing and installing components
