Dell Precision 7780 - Secondary M.2 Solid-State Drive; Removing the Secondary M.2 Solid-State Drive

Steps
1. Place the SSD onto its slot on the system chassis.
2. Replace the (M2x2.5) screw to secure the SSD to the system chassis.
3. Replace the (M2x2.5) screw to secure the SSD thermal plate to the SSD carrier and slide the SSD release latch into the lock
position.
Next steps
1. Install the base cover.
2. Follow the procedure in after working inside your computer.
Secondary M.2 solid-state drive
Removing the secondary M.2 Solid-state drive
Prerequisites
NOTE: For computers shipped with M.2 2280 PCIe Gen4 SSD installed in slot 4, 2, 3 and 5.
42 Removing and installing components
