Installing The Hard Drive
1. Slide the hard drive back into the cage.
2. Replace the screws to secure the hard drive to the hard-drive cage.
3. Slide and push the hard-drive bracket into the chassis to secure it.
4. Tighten the screw to secure the hard-drive bracket to the chassis.
5. Install the
rear stand
.
6. Install the
rear I/O cover
.
7. Install the
rear cover
.
8. Follow the procedures in
After Working Inside Your Computer
.
31
