Removing The System Board
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the rear cover .
3. Remove the rear stand .
4. Remove the rear I/O cover .
5. Remove the rear stand cover .
6. Remove the system board shield .
7. Remove the CPU fan .
8. Remove the CPU heatsink .
9. Remove the memory module .
10. Remove the WLAN card .
11. Remove the coin-cell battery .
12. Remove the processor .
13. Disconnect all the cables connected to the system board.
14. Remove the screws that secure the system board to the chassis.
