8. Remove the speakers from the computer.
Installing The Speakers
1. Place the speakers on the chassis.
2. Tighten the screws to secure both the speakers in place.
3. Connect the speaker cable to the system board.
4. Install the
system board shield
.
5. Install the
rear I/O cover
.
6. Install the
rear stand
.
7. Install the
rear cover
.
8. Follow the procedures in
After Working Inside Your Computer
.
40
