Removing The Heatsink Fan
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the rear cover .
3. Remove the rear stand .
4. Remove the rear I/O cover .
5. Remove the system board shield .
6. Remove the screws that secure the fan to the chassis.
7. Disconnect the heatsink fan cable from the system board.
