Communication
Wireless internal wireless local area network
(WLAN), WiFi, and Bluetooth
Expansion Bus
Bus type PCIE2.0
Bus speed 5.0 Gb/s
Expansion Cards
Mobile PCI Express Module WLAN & TVT Mini PCIE Module
Drives
Externally accessible one 5.25 inch drive bay
Internally accessible one 3.5 inch SATA drive bay
External Connectors
Audio:
Left Panel two connectors for headphone and
microphone
Back panel one line-out connector
Network one RJ–45 connector
USB:
Left panel two USB 2.0 connectors
Back panel four USB 2.0 connectors
Video one VGA connector
Memory card reader one 8-in-1 memory card reader
System Board Connectors
Serial ATA two
Memory two So-DIMM
Processor fan one 4–pin connector
97
