Steps
1. Using the alignment posts and rubber grommets, place the speakers in the slots on the palm-rest and keyboard assembly.
2. Route the speaker cable through the routing guides on the palm-rest and keyboard assembly.
3. Connect the speaker cable to the system board.
Next steps
1. Install the battery.
2. Install the base cover.
3. Follow the procedure in after working inside your computer.
Heat sink
Removing the heat sink - UMA
Prerequisites
NOTE: The heat sink type in your computer varies depending on the configuration ordered.
Disassembly and reassembly 37
