Delta Controls eZFC-424R4-24 User Manual

enteliZONE Database Configuration Objects
Page 74 of 84 eZFC-424R4-24 Application Guide
Edition 2.6
Object Name Object Ref Default Description
Damper1 Feed-
back
AV13 0 %
Position feedback signal from a
damper.
FanSpdCtrl
AV1
(ManualFanSpeedCmd)
% Manual supply fan input.
FanSpdSwitch
OffResistance
AV192 0 kohm
Resistance of the fan speed
switch when it is in the off
position.
FanSpdSwitch
AutoResistance
AV193
100,000
kohm
Resistance of the fan speed
switch when it is in the Auto
position.
FanSpdSwitch
Fan1Resistance
AV194 5 kohm
Resistance of the fan speed
switch when it is in the Fan
Speed 1 position.
FanSpdSwitch
Fan2Resistance
AV195 10 kohm
Resistance of the fan speed
switch when it is in the Fan
Speed 2 position.
FanSpdSwitch
Fan3Resistance
AV196 30 kohm
Resistance of the fan speed
switch when it is in the Fan
Speed 3 position.
FanStatus MV7 NotUsed_ Status of the zone supply fan.
WindowContact MV6 NotUsed_
Window contact to detect open
windows in order to control
local heating or cooling.
Condensate
Switch
MV9 NotUsed_
Used to disable cooling when
condensate is detected in the
bottom of the unit.
Fault MV10 NotUsed_
Used to display equipment
working status.
Filter Status MV11 NotUsed_
Switch placed across an air
filter to provide a signal to let
operators know when it is time
to change the filter.
HeatCool
ChangeOver
Status
MV803 NotUsed_
The output status of the 2-pipe
fan coil.
