Accessory 24E2A
SPECIFICATIONS
Environmental Specifications
Description Specification Notes
Operating Temperature
0°C to 45°C,
Storage Temperature
-25°C to 70°C
Humidity
10% to 95 % non-condensing
Physical Specifications
Description Specification Notes
Dimensions w/o Option 1A
Length: 16.256 cm (6.4 in.)
Height: 10 cm (3.94 in.)
Width: 2.03 cm (0.8 in.)
Dimensions with Option 1A
Length: 16.256 cm (6.4 in.)
Height: 10 cm (3.94 in.)
Width: 4.06 cm (1.6 in.)
Weight w/o Option 1A 192 g Front Plate included
Weight with Option 1A 370 g Front Plate included
Terminal Block Connectors
FRONT-MC1,5/12-ST3,81
FRONT-MC1,5/5-ST3,81
FRONT-MC1,5/3-ST3,81
Terminal Blocks from Phoenix
Contact. UL-94V0
DB Option Connectors
DB15 Female
UL-94V0
The width is the width of the front plate. The length and height are the dimensions of the PCB.
Specifications 3
