Accessory 24E2A
Mating Connectors
Terminal Block Connectors
Name Manufacturer Pins Type Details
TB1- Top Phoenix Contact 12 FRONT-MC1,5/12-ST3,81 Encoder 1 Inputs
TB2- Top Phoenix Contact 12 FRONT-MC1,5/12-ST3,81 Encoder 2 Inputs
TB3- Top Phoenix Contact 3 FRONT-MC1,5/3-ST3,81 Compare Outputs
TB1- Bottom Phoenix Contact 12 FRONT-MC1,5/12-ST3,81 Amplifier 1 Outputs
TB2- Bottom Phoenix Contact 12 FRONT-MC1,5/12-ST3,81 Amplifier 2 Outputs
TB3- Bottom Phoenix Contact 3 FRONT-MC1,5/3-ST3,81 External Power Inputs
TB1- Front Phoenix Contact 5 FRONT-MC1,5/5-ST3,81 Channel 1 Flags
TB2 Front Phoenix Contact 5 FRONT-MC1,5/5-ST3,81 Channel 2 Flags
DB15 Connector Option
Name Manufacturer Pins Type Details
J1- Top AMP 15 AMP 745072-2 Encoder 1 Inputs and
Compare Outputs
J2- Top AMP 15 AMP 745072-2 Encoder 2 Inputs and
Compare Outputs
J1- Bottom AMP 15 AMP 745072-2 Amplifier 1 Outputs and
Analog Power Inputs
J2- Bottom AMP 15 AMP 745072-2 Amplifier 2 Outputs and
Analog Power Inputs
Indicators
LED Color Description
D5 Amber Amplifier 1 Enabled
D6 Amber Amplifier 2 enabled
D10 Green Encoder 1 Power OK
D11 Green Encoder 2 Power OK
D17 Green Analog Power Good
