Accessory 24E2A
Connector TB1 Front- Limits 1
Pin# Symbol Function Description Notes
1 USER1 Input General Capture Flag Sinking or sourcing
2 PLIM1 Input Positive Limit Flag Sinking or sourcing
3 MLIM1 Input Negative Limit Flag Sinking or sourcing
4 HOME1 Input Home Flag Sinking or sourcing
5 FLG_1_RET Input Return For All Flags +V (12 to 24V) or 0V
Connector TB2 Front- Limits 2
Pin# Symbol Function Description Notes
1 USER2 Input General Capture Flag Sinking or sourcing
2 PLIM2 Input Positive Limit Flag Sinking or sourcing
3 MLIM2 Input Negative Limit Flag Sinking or sourcing
4 HOME2 Input Home Flag Sinking or sourcing
5 FLG_2_RET Input Return For All Flags +V (12 to 24V) or 0V
Acc-24E2 Terminal Block Description 41
